Antenna 5.xGHz » ARL-GD5828F
4.9-5.8GHz 28dBi Die Cast Grid N Female pigtail
[0484][ARL-GD5828F]
The product is
no longer available
Prices exclude VAT

4.9-5.8GHz 28dBi Die Cast Grid N Female pigtail

Description :

The antenna is an Aluminum-Magnesium (Al-Mg) alloy die cast construction which is then UV powder coated for additional environmental protection, durability and aesthetics.

The antenna is constructed of 2 separate light weight but superior strenght die cast aluminum pieces which are assembled together during installation.

The antenna comes complete with the die cast grid, feedhorn with 70cm pigtail (N-Male connector), and heavy duty mounting bracket.

The bracket gives up to 45o of tilt angle. Because of it's grid design the antenna offers excellent wind loading characteristics. The antenna can be installed in Vertical or Horizontal Polarization.

Specifications:
Frequency Range 4940*5850 MHz
Input Return Loss (S11) -14 dB
VSWR 1.5 : 1
Impedance 50 ohm
Input Power 50W
Operating Temperature
-45°C  to +70°C
Gain 28 dBi
3dB Beam Angle <8°
Front to Back 25 dB
Cross Pol Rejection 26 dBi
Side Lobe -20 dB
Weight 3.6 Kg

Specifications:
Frequency Range 4940*5850 MHz
Input Return Loss (S11) -14 dB
VSWR 1.5 : 1
Impedance 50 ohm
Input Power 50W
Operating Temperature -45°C  to +70°C
Gain 28 dBi
3dB Beam Angle <8°
Front to Back 25 dB
Cross Pol Rejection 26 dBi
Side Lobe -20 dB
Weight 3.6 Kg
