APC 2S-20
802.11N products
The APC 2S-20 presents a 2.4GHz CPE product with superior performance building long distance links. This product is equipped with an extreme output power (up to 31 dBm) 802.11n radio that was created with a unique hardware design and coupled with a reliable, feature-rich operating system. This device also has a robust, IP-65 compliant enclosure which is combined with a high-gain grid antenna, and emits EIRP up to 300 W. The APC 2S-20 is generally designed for CPE applications but can also act as an access point thus allowing point to point network applications.
The included, robust software engine allows the APC 2S-20 to work as bridge or as a router, provides a user-friendly Adobe Flex - based GUI with instant changes, includes useful installation tools (Site survey, Antenna alignment, Delayed reboot, Spectrum analyzer), and also is compatible with Wireless Network Management System for one of the most advanced management tools on the market.
| Package Contents: |
|---|
| 1 x Quick installation Guide
|
| 1 x Antenna
|
| 1 x Square-pipe
|
| 1 x PAC 2S-20 Antenna feeder
|
| 1 x Base frame
|
| 2 x U Bolt M6
|
| 2 x Hook
|
| 1 x Reflector_3
|
| 1 x PoE Injector
|
| 2 x Frame_2
|
| 1 x AC Adapter
|
| 1 x RJ45 Rubber gland
|
| 2 x ISO 4017 - M5 x 16-S
|
| 2 x ISO 4017 - M6 x 12
|
| 2 x Hexagon nut ISO 4032 - M5 - W - N
|
| 4 x Hexagon nut ISO 4032 - M6 - W - N
|
| 6 x Spring washer DIN 128 - M6 |
| Additional Images: |
|---|
 |
|
