The TL-WN821NC Wireless N USB Adapter complies with IEEE 802.11n (Draft 2.0), IEEE 802.11g, and IEEE 802.11b standards. Wireless transmission rates can reach up to 300Mbps.
The adapter employs MIMO technology and has internal Intelligent Antennas providing even better wireless performance, transmission rates, stability and coverage. At the same time, CCA technology automatically avoids channel conflicts using its channel selection feature.
This product supports 64/128-bit WEP encryptions, as well as WPA/WPA2 and WPA-PSK/WPA2-PSK encryptions and mechanisms in addition to the adapter’s QSS (Quick Secure Setup) feature, allowing users to quickly and easily setup wireless security.
This product can also simultaneously operate bandwidth intensive applications such as voice, and video. Applications using a lot of bandwidth that are sensitive to interruptions such as voice and video applications are given priority in order to assure quality. It also works well with other 11g and 11n protocol wireless products.
TL-WN821NC equipped with 1.5m extension cable along with USB cradle, which allow you to save USB port space, and extend the USB connection length up to 5 feet, making it more convenient to plug the USB device in & out of the USB socket. Its elegant and stylish design is suitable for home deployment and will even improve the look of your home and office.
|
Software Specification
|
|
Standards
|
IEEE 802.11n(draft 2.0), IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK
|
|
Wireless Signal Rates With Automatic Fallback
|
11n: 270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps
11g: 54/48/36/24/18/12/9/6M（adaptive）
11b: 11/5.5/2/1M（adaptive）
|
|
Frequency Range
|
2.4-2.4835GHz
|
|
Wireless Transmit Power
|
20dBm(MAX)
|
|
Modulation Type
|
OFDM/CCK/16-QAM/64-QAM
|
|
Receiver Sensitivity
|
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
|
|
Security
|
64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
|
|
Support Operating System
|
Windows 2000/XP/Vista
|
|
Hardware Specification
|
|
Interface
|
USB 2.0 Hi-Speed
|
|
Antenna Type
|
Internal Omni-directional Antennas
|
|
Certifications
|
CE, FCC
|
|
Operating temperature
|
0°C~40°C (32℉~104℉)
|
|
Storage temperature
|
-40°C~70°C (-40℉~158℉)
|
|
Relative humidity
|
10% ~ 90%, non condensation
|
|
Storage Humidity
|
5%~95% non-condensing
|
|
Dimensions
|
3.7 x 1.0 x 0.4in. (93.5 x 26 x 11mm)
|
