Περιγραφή :
The RooTenna® 2 panel antenna offered by Pacific Wireless was developed to allow integration of the customers’ radio equipment inside the weatherproof compartment. The expanded radio compartment is big enough to house transceivers, amplifiers, and other electronic equipment. The antenna design utilizes a wideband element array over a solid 8.5” square backplane for consistent performance over a wide bandwidth. The housing is UV stabilized ABS plastic. The backplate is alodine coated aluminum with stainless steel fasteners. All bracket fasteners are stainless steel for corrosion protection. There are qty 4 8-32 threaded standoffs provided inside the enclosure for customer mounting. Included with the Roo2 are a customer mounting plate and an RJ45 passthru Ethernet feedthru.
 Datasheet
|
Features :
Compact 19 dBi Antenna Gain
9” x 9” x 1” Weatherproof Radio Compartment
Vertical or Horizontal Polarization, Beamwidth 35 deg
SMA Female connector
|
 |
NOTE : Pigtail sold seperately in our Rootenna pigtail section
|
Parameter
|
Min
|
Typ
|
Max
|
Units
|
|
Frequency Range
|
5150
|
|
5850
|
MHz
|
|
VSWR
|
|
1.5:1
|
|
|
|
Impedance
|
|
50
|
|
OHM
|
|
Input Power
|
|
|
20
|
W
|
|
Operating Temperature
|
-45
|
|
+70
|
Deg C
|
|
Gain
|
|
19
|
|
dBi
|
|
3db Beam Angle (E-Plane)
|
|
15
|
|
Deg
|
|
3dB Beam Angle (H-Plane)
|
|
15
|
|
Deg
|
|
Front to Back
|
25
|
|
|
dB
|
|
Weight
|
|
0.8
|
|
kg
|
|
Outside Dim (L x W x H)
|
267 x 267 x 67
|
mm
|
| Το προϊόν αποτελείται τα παρακάτω μέρη: |
| |
1 x Mounting Bracket for small RooTenas |
1 x Small Rootenna backplate |
1 x Customer Install Plate |
1 x RJ45 Ethernet Connector System |
1 x 19dBi 5.1-5.8GHz Low profile Panel Antenna with Radio Pouch |
|
| |
|
