The new Lan Controller v4.0 integrates our previous IoT experiences into one universal device. It represents a seamless continuation of the previous LAN Controller series, now in a more convenient form.
Dual communication interface: You can use a wired Ethernet connection, wireless Wi-Fi, or both at the same time.
LAN Controller v4 can be fully configured from the website, available on the built-in web server.
It is also possible to send any commands to the device via the HTTP protocol (omitting the website) or MQTT (after configuring the connection)
|
Specifications: |
|
Part # |
LANKON-005
|
|
Supply voltage |
8-58V |
|
Power consumption |
0.5W (witdout relays enabled) |
|
PoE power supply |
802.3af PoE / Mode A
Passive PoE / Mode B
(jumper configurable) |
|
Interfaces |
Etdernet 10/100 Mbit/s
Wi-Fi 802.11n |
|
Measurement interfaces |
-
Modbus RTU
-
4 digital inputs
(L = 0 - 0.3 V, H = 0.8 - 30 V for INPD1,
L = 0 - 0.1 V, H = 1.3 - 30 V for INPD2-INPD4)
-
3 analog inputs
(0.1 - 3.3 V lub 0 - 58 V for INPA1-INPA2,
0.1 - 5 V lub 0 - 58 V for INPA3)
-
1-Wire (shared RJ12 connector)
-
I2C (shared RJ12 connector)
|
|
Outputs |
-
1 relay output (NO, C, NC) 255VAC 10A
-
4 outputs in OC standard (open collector)
-
1 transistor output (V = VCC)
-
3 PWM outputs (3.3V @ 1-1000000 Hz)
|
|
Operating temperature range |
-20°C to +85°C |
|
Dimensions |
106 x 79 x 38mm |
|
Weight |
130g |
|
DIN rail mounting |
Yes (35mm) |
| Package Contents: |
|---|
| 1 x Lan Controller v4.0
|
| 1 x Plastic Case
|
| 1 x Plastic DIN mount |
|
