2 way Signal Splitter N-type Female

Description :
Signal Splitters are used for connecting more than one antenna to a single radio. They feature weather-proof construction and can be installed indoors or outdoors. DC passthrough ensures great performance even when used with amplified systems. Signal Splitters are also available in 3-way with N-Female connectors.

Note: Any open splitter ports should be terminated with a 50 Ohm terminator.

Features :

Compatible with 802.11b/g applications

Industrial grade

RoHS Compliant

Aluminum construction

Weatherproof for indoor or outdoor use

DC power will pass to all ports

Available with N-Female connectors

Specifications :

Frequency Range (MHz) 900-2600 MHz

Insertion Loss (dB) <= 3.4

Amplitude Balance (dB) <= 0.2

Phase Balance 5°

Standing Wave VSWR (in) <= 1.25

Standing Wave VSWR (out) <= 1.20

Isolation (dB) >= 22

Power (W) >= 30

Dimension (mm) 75 x 50 x 20

Weight 300 gr

Connectors N Female
