CRS418-8P-8G-2S+RM - 16+1 x Gigabit Ethernet ports (8x with PoE-out 48v/24v), dual 10G uplinks, and a powerful quad-core 2.2 GHz ARM CPU
The CRS418-8P-8G-2S+RM combines 16 Gigabit Ethernet ports (eight of them with PoE-out 48v/24v), two 10G SFP+ cages, USB 3 connectivity, and a powerful quad-core 2.2 GHz CPU in a clean, durable rackmount enclosure.
Also, there’s a Gigabit management port with a direct CPU line. This is a serious upgrade for anyone looking to replace a jungle of devices with one smart multitasker – built for real routing workloads, high-bandwidth uplinks, and clean cable management.
Whether you’re powering up access points and CCTV cameras, running a fast NAS with a bunch of modern workstations, or managing the routing in your mid-sized office, CRS418 handles it all with ease – and on a budget!
|
Specifications |
|
Product code |
CRS418-8P-8G-2S+RM |
|
Architecture |
ARM 64bit |
|
CPU |
IPQ-8072 |
|
CPU core count |
4 |
|
CPU nominal frequency |
2208 MHz |
|
Switch chip model |
98DX226S |
|
RouterOS license |
5 |
|
Operating System |
RouterOS v7 |
|
Size of RAM |
1 GB |
|
Storage size |
128 MB |
|
Storage type |
NAND |
|
MTBF (Approximately) |
200.000 hours at 25°C |
|
Tested ambient temperature |
-20°C to 70°C |
|
Powering |
|
Number of AC inputs |
2 |
|
AC input range |
100-240 |
|
Number of PSU slots |
2 |
|
Frequency (Hz) |
50-60 |
|
Max power consumption |
215 W |
|
Max power without attachments |
28 W |
|
Cooling type |
4 fans |
|
PoE-out
|
|
PoE-out ports |
Ether1-Ether8 |
|
PoE out |
802.3af/at or 24v |
|
Max out per port output (input 18-30 V) |
1.1 A |
|
Max out per port output (input 30-57 V) |
0.55 A |
|
Max total out (A) |
5.4 A |
|
Total output current |
5.4 |
|
Total output power |
150 |
|
Ethernet |
|
10/100/1000 Ethernet ports |
17 |
|
Number of 1G Ethernet ports with PoE-out |
8 |
|
Fiber |
|
SFP+ ports |
2 |
|
Peripherals |
|
Serial console port |
RJ45 |
|
Number of USB ports |
1 |
|
USB Power Reset |
Yes |
|
USB slot type |
USB 3.0 type A |
|
Max USB current (A) |
1 |
|
Other |
|
CPU temperature monitor |
Yes |
|
Current Monitor |
Yes |
|
PCB temperature monitor |
Yes |
|
Voltage Monitor |
Yes |
|
Mode button |
Yes |
| Package Contents: |
|---|
| 1 x CRS112-8P-4S-IN
|
| 2 x AC Cables - IEC
|
| 1 x K45 screw kit
|
| 1 x Rackmount Ears |
|
