PoE » 802.3af/at Switch » PSBT-19-16P-250
MaxLink PSBT-19-16P-250, 19-Port (16x100M PoE + 2x1000M + 1xSFP) switch, 802.3af/at/bt
[2873][PSBT-19-16P-250]
Price: 134,83€
 Order or Qty  Price
 > 500€  5+   132,13€
 > 1000€  10+   129,44€
 > 2000€  20+   126,74€
 > 5000€  40+   124,04€
 > 10000€  100+   121,35€
Prices exclude VAT

MaxLink PSBT-19-16P-250, 19-Port (16x100M PoE + 2x1000M + 1xSFP) switch, 802.3af/at/bt

In Stock: 1
Order Qty:
PSBT-19-16P-250  - a 16 x 10/100Mbps PoE + 2 10/10//1000Mbps Uplink + 1 Optical 1000Mpbs Combo switch without management.

Automatically detects and powers devices supporting PoE standard 802.3af/at (max. 30 W/port) on ports 1 to 16, on port 1 even supports PoE standard 802.3bt (60 W).

Ports 17 and 18 serve as 1000Mbps uplinks and do not support PoE. The total budget for powering the connected devices is 200 W using AC source 230V.

The switch automatically balances the power for individual ports according to the consumption of the device.

802.3bt support! Port 1 additionally supports the 802.3bt standard, where the output power of up to 60 W is available for the connected device!

The switches are now also equipped with a function Watchdog. If the Ethernet link is not detected for about 1 minute and the power supply is active at the same time, the supply voltage will be interrupted and the connected device will be restarted.

Switch has a manual mode switch Normal "N": The switch powers the device at a distance of max. 100 m. or up to 250 m with a reduced throughput of 10 Mbps per port.

VLAN: Ports are logically separated from each other, in this mode unwanted broadcast storms can be avoided.

Specifications:
Part No PSBT-19-16P-250
Ports
16 x 10/100 Mbps
2 x 10/100/1000Mbps
1 x SFP 1000Mbps Combo
Power:
DC Connector
230v AC
PoE type PoE out
PoE-Out 802.3af, 802.3at, 802.3bt
PoE Out ports
16 (1-16)
UpLink ports
2 (17-18)
Optical 1 (1000Mbps Combo)
PoE budger 200W
Physical:
Chassis Steel
Fan
2 : 40x40mm
Operating temp -10°C to 55°C
Dimensions 295 x 195 x 45 mm
Weight 2450gr


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
