Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments. Combining the latest 802.11ac Wave 2 technology and the field proven, scalable performance of ePMP, the Force 300-13L delivers up to 400 Mbps of capacity. The Force 300-13L is a powerful, yet affordable subscriber module compatible with the ePMP3000 Access Point, while also interoperating with the ePMP2000 to enable seamless migration to 802.11ac Wave 2 technology.
FEATURES:
-
Cambium Networks’ ePMP™ Force 300-13L is an affordable subscriber module well-suited for markets where price is key and networks where ranges are shorter.
-
The ePMP 300-13L is designed to operate in high interference environments and provides throughput of up to 400 Mbps with bi-directional traffic of real user data.
-
Configurable Modes of operation ensure high performance and low round-trip latency in both symmetrical and asymmetrical traffic.
-
QoS management offers outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority.
-
The ePMP Force 300-13L is available in 5 GHz only, supports a peak throughput of 400Mbps and does not support a dedicated spectrum analyzer.
-
Installation is a breeze for pole and wall mounting.
-
The ePMP Force 300-13L is compatible with ePMP 1000, ePMP 2000 and ePMP 3000 Access Points.
-
The ePMP Force 300-13L is available in EMEA, CALA and APAC regions where type approved. NOT available in FCC regions.
|
Specifications |
|
Connectors and Interfaces |
|
LAN speed: |
(1) 10/100/1000Mbps |
|
Gigabit LAN: |
Yes |
|
Physical characteristics |
|
Purpose: |
Outdoor |
|
Operating temperature [°C]: |
-30 up to 55 |
|
Weight [g]: |
350 |
|
Depth [mm]: |
58 |
|
Width [mm]: |
77 |
|
Height [mm]: |
235 |
|
Power |
|
Power over Ethernet: |
14 .. 30V DC |
|
Power type: |
PoE |
|
PoE type: |
PoE-In (only) |
|
Max. power consumption [W]: |
12 |
|
Software |
|
Operating mode: |
Client |
|
IPv6 support: |
Yes |
|
Default login and password: |
admin / admin |
|
Wireless features |
|
Wireless frequency: |
5 GHz |
|
WiFi standards: |
802.11ac, 802.11n, 802.11a |
|
Transmission speed - WiFi 5GHz [Mb/s]: |
866 |
|
Tx power 5GHz [dBm]: |
27 |
|
Security: |
128bit AES |
|
5GHz MIMO: |
2 x 2 |
|
Azimuth beam width (-6dB) [°]: |
45, 15 |
|
Type of antenna: |
Built-in |
|
Internal antennas: |
2 |
|
Antenna gain [dBi]: |
13 |
| Package Contents: |
|---|
| 1 x C050910C233A |
| Additional Images: |
|---|
 |
 |
|
