cnPilot E600 - without PoE injector
High-performance, gigabit speed, beamforming, multi-user access point (MU-MIMO) 802.11ac wave 2 E600 with 4x4 antenna array implements the latest standards. Ideal for almost any location that requires high capacity, high reach and / or high client capacity. The ideal workhorse to meet the high demand for operation in classrooms (schools), indoor public spaces, shops, hotels or corporate offices.
Local and cnMaestro administration
-
Simple "onboarding"
-
Inventory tracking and monitoring
-
Bulk configuration and upgrade
-
Control panel display with alarms
-
Troubleshooting
-
Great organization of the facility
Roaming
The E600 supports seamless roaming for up to 1,000 clients without the need for a network controller. Hosting a hotspot on the access point itself offers simplicity without a controller.
Coverage, capacity, speed
The fully rated E600 has a maximum transmission power of 25 dBm and is DFS certified to use more dedicated 5 GHz DFS channels - offering more flexibility than ever before for both coverage and capacity. Bandwidth management through broadcast fairness, increased performance through automatic channel search (ACS), and higher bandwidth speeds from client devices ensure that your network can adapt to dynamic client behavior.
High availability and density
The capacity of 256 concurrent client associations and 16 SSIDs together with dual integrated Active / Standby memory banks ensure that the E600 combines high density and high availability.
The 802.11ac wave 2 E600 comes with a free controller and no license AP management fees
|
Specifications |
|
Connectors and Interfaces |
|
LAN speed: |
(2) 10/100/1000Mbps |
|
Gigabit LAN: |
Yes |
|
USB: |
Yes |
|
Physical characteristics |
|
Purpose: |
Indoor |
|
Operating temperature [°C]: |
0 up to 50 |
|
Weight [g]: |
558 |
|
Depth [mm]: |
42 |
|
Width [mm]: |
180 |
|
Height [mm]: |
180 |
|
Power |
|
Power over Ethernet: |
802.3at |
|
PoE type: |
PoE-In (only) |
|
Max. power consumption [W]: |
17 |
|
Power via connector/terminal: |
12V / 3A |
|
Software |
|
Operating mode: |
Access Point |
|
IPv6 support: |
Yes |
|
Default IP address: |
192.168.0.1, Dynamic from DHCP |
|
Default login and password: |
admin / admin |
|
Wireless features |
|
Wireless frequency: |
2.4 + 5 GHz (dual band) |
|
WiFi standards: |
802.11ac, 802.11ac - wave2, 802.11n, 802.11a, 802.11b/g |
|
MU-MIMO: |
Yes |
|
Hotspot 2.0: |
Yes |
|
Transmission speed - WiFi 2.4GHz [Mb/s]: |
400 |
|
Transmission speed - WiFi 5GHz [Mb/s]: |
1733 |
|
Tx power 2.4GHz [dBm]: |
24 |
|
Tx power 5GHz [dBm]: |
28 |
|
2.4GHz MIMO: |
2 x 2 |
|
5GHz MIMO: |
4 x 4 |
|
Type of antenna: |
Built-in |
|
Roaming: |
Yes |
|
Antenna gain [dBi]: |
6 |
| Package Contents: |
|---|
| 1 x PL-E600X00A-EU
|
| 0 x PoE injector |
| Additional Images: |
|---|
 |
 |
|
