Cambium Networks ePMP 6 GHz Force 4600C SM Radio (EU)
The Cambium Networks ePMP Force 4600C is a high-performance, connectorized subscriber module designed for both point-to-point (PTP) and point-to-multipoint (PMP) fixed wireless broadband applications.
Operating in the 6 GHz band, it leverages 802.11ax (Wi-Fi 6) technology to deliver robust and scalable connectivity solutions.
Features
-
High Throughput: Supports over 2 Gbps capacity using 160 MHz channels, ensuring high-speed data transmission.
-
Low Latency: Achieves latencies under 5 ms with ePTP (enhanced Point-to-Point) technology, suitable for latency-sensitive applications.
-
Connectorized Design: Equipped with 2 x RP-SMA connectors, allowing integration with various external antennas for deployment flexibility.
-
Wide Frequency Range: Operates between 5.725 GHz and 7.125 GHz, providing a broad spectrum for deployment.
-
Flexible Channel Widths: Supports 20, 40, 80, and 160 MHz channel widths, adaptable to different network requirements.
-
Advanced Management: Compatible with Cambium Networks' cnMaestro™ management system for streamlined provisioning, monitoring, and upgrades.
-
Robust Build: IP67-rated for outdoor use, operating reliably in temperatures from -40°C to 55°C.
-
Additional Features: Includes a Power over Ethernet (PoE) injector and pole mount hardware for ease of installation.
|
Specifications: |
|
Frequency Range |
5725–7125 MHz |
|
Channel Widths |
20 / 40 / 80 / 160 MHz |
|
Channel Spacing |
Configurable in 5 MHz increments |
|
Physical Layer |
ePMP air interface with 2x2 MIMO/OFDMA based on 802.11ax |
|
MAC Layer |
Cambium proprietary |
|
Maximum Capacity |
2+ Gbps (PTP applications) |
|
Latency |
Less than 5 ms (with ePTP technology) |
|
Transmit Power Range |
+3 to +30 dBm (combined, to regional EIRP limit) |
|
Receive Sensitivity @20 MHz |
MCS 0 = -92 dBm to MCS 13 (4096 QAM-5/6) = -53 dBm (per chain) |
|
Receive Sensitivity @40 MHz |
MCS 0 = -89 dBm to MCS 13 (4096 QAM-5/6) = -50 dBm (per chain) |
|
Ethernet Interface |
100/1000 BaseT, auto-negotiated, 802.3at compliant; includes SFP+ port |
|
Supported Protocols |
IPv4/IPv6, UDP, TCP, IP, ICMP, SNMPv2c, HTTPS, STP, SSH, IGMP snooping |
|
Network Management |
HTTP/HTTPS, SNMPv1/2/3, SSH |
|
VLAN Support |
802.1Q with 802.1p priority |
|
Surge Suppression |
1 Joule Integrated |
|
Environmental Rating |
IP67 |
|
Operating Temperature |
-40°C to 55°C |
|
Power Consumption |
Approximately 28 W |
|
Dimensions |
Approximately 256 x 125 x 47 mm |
|
Weight |
Around 0.73 kg without bracket |
|
Connector Type |
2 x RP-SMA connectors |
|
Included Accessories |
Power over Ethernet (PoE) injector and pole mount hardware |
|
Warranty |
3-year hardware warranty |
| Package Contents: |
|---|
| 1 x 4600C SM
|
| 1 x PoE Power adapter
|
| 1 x Power cord (EU)
|
| 1 x Mounting KIT
|
| 1 x Metal ring |
|
