Mimosa » 100-00075
Mimosa N5-360, 2x 2x2 MIMO 180° sector antenna, 15dBi, 4x N female
[2603][100-00075]
Price: 258,95€
 Order or Qty  Price
 > 500€  5+   256,36€
 > 1000€  10+   253,77€
 > 2000€  20+   251,18€
 > 5000€  40+   248,59€
 > 10000€  100+   246,00€
Prices exclude VAT

Mimosa N5-360, 2x 2x2 MIMO 180° sector antenna, 15dBi, 4x N female

Ships in:
3-5 working days
Quantity: 8
Order Qty:
UPC:708747437560
EAN:10000075

N5-360

Introducing the industry’s first 4-port, beamforming, 360º antenna specifically designed exclusively for Mimosa’s A5c access point. The N5-360 antenna’s unique design incorporates quad-180º overlapping antenna polarizations, doubling the coverage of Mimosa MicroPoP deployments with 3 dB of beamforming gain. The N5-360 boosts throughput by providing balanced dual-stream coverage over 360º of azimuth. Without sacrificing performance, the N5-360 operates over a wide frequency range, from 4.9 to 6.4 GHz, supporting licensed public safety bands and other expanded frequencies, where permitted by region.

LONGER-RANGE MICROPOPS

Double the coverage area with 60% longer reach for MicroPoP deployments, easily handling deployments to homes within 500 m in dense, last mile, suburban areas.

​WIDE-FREQUENCY RANGE

The only antenna available for use between 4.9 to 6.4 GHz, delivering incredible spectrum flexibility.

OPTIMIZED FOR 360º THROUGHPUT

Enhanced C5 and C5c subscriber speeds through new, balanced, multi-stream technology.

BEAMFORMING INNOVATION

3 dB performance enhancement in a compact design, with all new quad-180º overlapping antenna polarizations that enable range-extending, beamforming technology.

Specifications:
Connectors and Interfaces
RF connectors: (4) N female
Physical characteristics
Wind load [km/h]: 160
Purpose: Outdoor
Weight [kg]: 1,1
Depth [mm]: 80
Width [mm]: 80
Height [mm]: 492
Wireless features
Cross-Pol Isolation [dB]: 25
MIMO, SISO: 2 x 2
Polarization: VH
Wireless frequency: 5 GHz
Azimuth beam width (-6dB) [°]: 360, 8
Antenna kind: Omnidirectional
Antenna gain [dBi]: 15


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 24 month(s)
