Aerial.net :: Cudy AP1200 Outdoor, AC1200 Gigabit AP/Repeater/Router/WISP Outdoor

Cudy » AP / MESH » AP1200 Outdoor

Cudy AP1200 Outdoor, AC1200 Gigabit AP/Repeater/Router/WISP Outdoor
[3406][AP1200 Outdoor]

Price: 32,20€

Prices exclude VAT

In Stock: 9

Available quantity within
3-5 working days: 46

Order Qty:

EAN:	6971690794347

AP1200 Outdoor - Indoor/Outdoor AC1200 Wi-Fi Access Point 1.0

A pole/wall-mounted WiFi AP with IP65 casing and PoE, ideal for park, farm, and parking lot environments.

	IP65, -40~65°C (-40~149°F), 4kV Surge
	4-stream dual-band Wi-Fi 5
	867 Mbps @ 5 GHz and 300 Mbps @ 2.4 GHz.
	1× Fast Ethernet Port
	24V Passive PoE
	30 Connected Devices
	Router/AP/RE/WISP/Client Modes

Product Links:
Product Page	Datasheet	Quick Start Guide

Specifications:
Model Version	AP1200 Outdoor 1.0
CPU CPU Details	580 MHZ Single-Core CPU
Memory/Storage Flash/ROM	8 MB (64 Mbit ) NOR
DDR/RAM	64 MB (512 Mbit) DDR2
Wireless 5 GHz Wi-Fi Speed	867Mbps
2.4 GHz Wi-Fi Speed	300Mbps
5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
Wi-Fi Antennas	2× Detachable
5 GHz Antenna Gain Max	4.4 dBi
2.4 GHz Antenna Gain Max	4.6 dBi
FEM or PA/LNA	5 GHz: 2× Internal 2.4 GHz: 2× Internal
Detachable Wi-Fi Antennas Connector	RP-SMA Female
Beamforming	True
Range Performance	Max: 170 m
Wall Performance	NA
Interfaces 10/100 Mbps RJ45 Ports	1
Ethernet Notes	Accepts PoE powering
LED	5 GHz Wi-Fi 2.4 GHz Wi-Fi LAN Internet System
Physical Buttons	WPS Button Reset Button
Power Input	PoE via Ethernet Port
Power Power Methods	Passive PoE
Passive PoE	24V
Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 24V Passive PoE
Max Power Consumption (W)	12 W
Idle Power Consumption (W)	2.5 W
Reliability EMS	ESD: Contact: 4kV; Air: 8kV IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV
Environment Operating Temperature	-20 ℃ ~ 60 ℃
Ingress Protection Rating	IP65 When devices is installed vertically
Certifications	FCC, CE
Mechanical Installation	Wall-mount Pole-mount
Dimension Device Body Each Antenna	240×100×53.7 mm 197.5×21.6×15.5 mm
Product Weight	415 g
Ordering Information Retail Package Weight	EU: 768 g
Retail Package Dimension	324×107×86 mm
