NF-488 PoE and Cable Tester - RJ45
[2703][NF-488]
Price: 39,15€
 Order or Qty  Price
 > 500€  5+   38,37€
 > 1000€  10+   37,58€
 > 2000€  20+   36,80€
 > 5000€  50+   36,02€
 > 10000€  100+   35,24€
Prices exclude VAT

NF-488 PoE and Cable Tester - RJ45

No Stock
Order Qty:
UPC:6971278906629

NF-488 - Cable tester with LCD for PoE type, PoE pair, voltage, cable continuity and power usage indication.

The Noyafa NF-488 is an indispensable device for testing PoE installations.

The device recognizes which lines have voltage, gives its value and determines the PoE standard.

They can also be connected in series between the switch and the powered device, thanks to which it is possible to obtain information about the current consumption and the power consumed by the receiver.

In addition to PoE testing, the NF-488 performs a standard wiremap test to validate the wiring.

NF-488 Transmitter Specifications:
Indicator LCD 128x64 mm, with back light
Continulity function Cable types CAT5,CAT6
Check UTP/STP cable YES
Cable short indicate YES
Max testing range 600m
Wire mapping Emitter +Remote
Emitter + switch/routor
PoE function Test range DC5-60V POE switch
Standard identify 802.3af/at and passive
Test range power 0-18W
Output interface YES
Power function Voltage test range DC0-60V
Current test range 0-3A
power test range 0-180W
Input voltage protection DC48V 5mA
Max working current ≤80mA
Loopback Compatible with 10M ,100M,1000M switch
Power supply 3*AAA
NF-488 Remote Specifications:
Ports RJ45
Function Wire mapping for network cable
Input voltage protection DC48V 5mA


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
