e-zy.net » EZ-POEPS05
PoE 10/100 Passive Splitter - cat5 - White
[2237][EZ-POEPS05]
Price: 0,97€
 Order or Qty  Price
 > 500€  5+   0,95€
 > 1000€  10+   0,93€
 > 2000€  20+   0,91€
 > 5000€  40+   0,89€
 > 10000€  100+   0,87€
Prices exclude VAT

PoE 10/100 Passive Splitter - cat5 - White

In Stock: 19
Order Qty:
UPC:728615666724

EZ-POEPS05

Features:

  • Cat5 Cable
  • RJ45 Input / Output connector
  • Input / Output common ground
  • Power / Data Splitter
  • Ethernet switches expand to Wireless AP

Input / Output Specifications :
DC Input Voltage 48V ± 5 %
DC Output Voltage 48V ± 5 %
Max Output Current 0.4A Max.
Over Current Protection None
General Specifications:
Operating Temperature 0oC ~ +50oC
Storage Temperature -20oC ~ +70oC
Humidity Up to 90%
Weight 50gr
Dimensions 160x22x21mm
Input Pins
RJ45 Plug
Output Pins
RJ45 Jack
1 Tx(+) Tx(+) 1
2 Tx (-) Tx (-) 2
3 Rx (+) Rx (+) 3
4 V+ N.C. 4
5 V+ N.C. 5
6 Rx (-) Rx (-) 6
7 GND N.C. 7
8 GND N.C. 8


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
