SST-AT14G POE Extender switch is used to extend Ethernet and POE power transmission distance through Cat5E/Cat6 cable.
Features unique design, 1 port PoE In and 3 ports PoE-Out, SST-AT14G can not only extend Ethernet and power transmission, but also simplify cabling by running one cable to power 3 POE devices, such as WiFi APs, IP camera, VoIP phone, door bell camera, etc.
|
Specifications: |
|
Part No |
SST-AT14G-C |
|
Ports |
5 x 10/100/1000 Mbs |
|
Power: |
|
PoE type |
PoE in/out |
|
PoE-In port#1 |
90W max |
|
PoE-Out port#2 |
60w max |
|
PoE-Out port#3-5 |
3w max / port |
|
PoE In |
PoE In (port 1) |
|
PoE Out |
PoE1-4 (ports 2-5) |
|
PoE budget |
30W |
|
Physical: |
|
Chassis |
ABS + PC |
|
Fan |
No |
|
Operating temp |
-10°C to 45°C |
|
Dimensions |
88 x 58 x 23mm |
|
Weight |
65gr |
| Package Contents: |
|---|
| 1 x SST-AT14G |
|
