SST-LP4EH2EHB, 6-Port (4+2) 10/100 24v Passive PoE switch, 75W
[3731][SST-LP4EH2EHB]

Price: 23,26€

Order or Qty		Price
> 500€	5+	22,79€
> 1000€	10+	22,33€
> 2000€	20+	21,86€
> 5000€	40+	21,40€
> 10000€	100+	20,93€

Prices exclude VAT

In Stock: 10

Order Qty:

UPC:	728615669411

SST-LP4EH2EHB - 6-Port (4+2) 10/100 24v Passive PoE switch, 75W

POE switch is used to extend Ethernet and POE power transmission distance through Cat5E/Cat6 cable.

Features unique design, 2 ports without PoE Uplink / NVR and 4 ports 24v Passive PoE-Out.

SST-LP4EH2EHB can not only extend Ethernet and power transmission, but also simplify cabling by running one cable to power 4 x 24v passive POE devices.

Product Links:
Datasheet

Port#	PoE	Power	Powering	Mode	+ Pins	- Pins
2-4	Out	15W/port	2-Pair	A	1,2	3,6

Specifications:
Standards	IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
PoE Ports	4x 10/100 Mbps RJ45 (Non-standard/Passive)
Uplink Ports	2x 10/100 Mbps RJ45
PoE Voltage	DC 24V (Non-standard)
PoE Pin Assignment	4/5 (+), 7/8 (-)
Max. PoE Power	75W (Total) / 15W (Per Port)
Data Transmission
Transmission Distance	100M: 100m / 10M: 250m
MAC Address Table	1K
Buffer Space	1 Mbit
MTBF	100,000 hours
Power & Environmental
Power Input	AC 100V - 240V @ 50/60Hz
Max. Device Consumption	75W
Operating Temperature	-10 ℃ to 60 ℃
Mechanical Details
Dimensions	200 x 118 x 45 mm
Weight	549 g
Case Material	Steel
Color	Black
Humidity	5% to 90% non-condensing
