Aerial.net :: Mercusys MS106LP, 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+

Mercusys » MS106LP

Mercusys MS106LP, 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+
[3499][MS106LP]

Price: 15,28€

Order or Qty		Price
> 500€	5+	15,12€
> 1000€	10+	14,97€
> 2000€	20+	14,82€
> 5000€	40+	14,66€
> 10000€	100+	14,51€

Prices exclude VAT

In Stock: 5

Order Qty:

EAN:	6957939001148

MS106LP - 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+

Unmanaged Mercusys PoE switch with (6) 10/100 Mbps of which ports 5 and 6 without PoE can serve as uplink and the remaining 4 ports support PoE out with 802.3af/at standard (up to 30W/port).

The total PoE budget is 40W.

The switch also enables PoE at a distance of 250m when switching a special switch, which causes the line speed on the PoE ports to drop to 10 Mbps, which is more than enough for image transmission from cameras.

PoE Auto Recovery ensuring automatic power restart for devices that stop communicating

Port isolation to determine end device communication only via the uplink port / gateway.

Product Links:
Product Page	Datasheet	Installation

Specifications:
Standards and Protocols	IEEE 802.3x Flow Control
Dimensions	99.89825mm
PoE Ports	Standard: Compliant with 802.3 af/at Powered Devices PoE Ports: Port 1- Port 4 PoE Power Budget: 40 W
Interfaces	6× 10/100 Mbps Ports, Auto-Negotiation, Auto MDI/MDIX
External Power Supply	External Power Adapter (Output: 53.5V/0.81A)
Installation	Desktop Wall Mount
Data Rates	10/100 Mbps at Half Duplex 20/200 Mbps at Full Duplex
Jumbo Frame	2 KB
MAC Address Table	2K
Max Power Consumption	1.87W（220 V / 50 Hz, no PD connected） 44.8W（220 V / 50 Hz, with 40W PD connected）
Max Heat Dissipation	6.34 BTH/h （no PD connected) 152.32 BTH/h（with 40W PD connected）

Package Contents:
1 x MS106LP
1 x Power Adapter
1 x Quick Installation Guide

Additional Images:

Return for:
Refund:	Store Credit:	Repair:
20 day(s)	40 day(s)	24 month(s)
