GS1024 - 24-Port Gigabit Ethernet Switch
Auto-negotiation RJ-45 ports can provide large file transferring and also be compatible with any 10/100/1000Mbps Ethernet devices.
IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode offer increased bandwidth to alleviate network congestion, making the switch work reliably.
Save power up to 40% - The GS1024 uses green Ethernet technology to make your network compatible without compromising performance.
The switch automatically powers down the ports that are idle and budgets power output for different Ethernet cable lengths. It helps you save power up to 40%.
|
Specifications: |
|
Model |
GS1024 |
|
Ethernet Standards |
IEEE 802.3/802.3u / 802.3ab
|
|
Protocol |
CSMA/CD |
|
Data Rate |
14,880 pps for 10Mbps
148,800 pps for 100Mbps
148,8000 pps for 1000Mbps
|
|
Transmission Method |
Store-and-Forward |
|
Switching Features |
MAC address auto-learning and auto-aging
Half and Full Duplex 48Gbps backplane bandwidth |
|
Interfaces |
24 x 10/100/100Base-TX Port |
|
LED Indicators |
LAN~LAN24, Power |
|
MAC Address Table |
8K MAC address table
|
|
Power Supply |
AC100~ 240V Integrated |
|
Dimensions W*D*H |
270*180*44mm |
|
Operating Temperatur |
0°C~40°C |
|
Storage Temperature |
-40°C~70°C |
|
Relative Humidity |
10%~90%, non-condensing |
|
Storage Humidity |
5%~95%, non-condensing |
