Aerial.net :: Cudy WR11000, 2.5G Tri-Band Wi-Fi 7 Mesh Router, BE11000 v1.0

Cudy » WR11000

Cudy WR11000, 2.5G Tri-Band Wi-Fi 7 Mesh Router, BE11000 v1.0
[3407][WR11000]

Price: 104,45€

Order or Qty		Price
> 500€	5+	103,40€
> 1000€	10+	102,36€
> 2000€	20+	101,31€
> 5000€	40+	100,27€
> 10000€	100+	99,23€

Prices exclude VAT

Available after:
25 Jul 2025

Order Qty:

EAN:	6971690793357

WR11000 - BE11000 2.5G Tri-Band Mesh Wi-Fi 7 Router1.0

A tri-band WiFi 7 router with an aggregate of 10.6 Gbps speed and four 2.5G ports, catering to latency-sensitive, speed-demanding, and large-scale scenarios.

	Qualcomm 1.5 GHz Quad-Core CPU
	6-Stream Tri-Band Wi-Fi 7
	5.7 Gbps + 4.3 Gbps + 688 Mbps ¹
	4× 2.5G Ethernet Ports
	300 Connected Devices ²
	Covers 140 m² (1,500 ft²) ³
	Cudy Mesh, VPN Server and Client
	Cudy App, Cloud Control

Product Links:
Product Page	Datasheet	Quick Start Guide	Support

Specifications:

Model Version

WR11000 1.0

CPU

1.5 GHz Quad-Core CPU, ARM Cortex-A53

Memory/Storage

Flash/ROM	128 MB (1 Gbit) NAND
DDR/RAM	512 MB (4 Gbit) DDR4

Wireless

6 GHz Wi-Fi Speed	5765 Mbps
5 GHz Wi-Fi Speed	4324 Mbps
2.4 GHz Wi-Fi Speed	688 Mbps
6 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
Wi-Fi Antennas	6× Fixed
6 GHz Antenna Gain Max	4.5dBi
5 GHz Antenna Gain Max	4.5dBi
2.4 GHz Antenna Gain Max	5dBi
FEM or PA/LNA	6 GHz: 2× High-Power 5 GHz: 2× High-Power 2.4 GHz: 2× Standard
Beamforming	True

Range Performance

Max: 240 m
Indoor WiFi range varies depending on the layout and wall materials.

Wall Performance

Two wooden walls with thickness < 10 cm
One concrete wall with thickness < 20 cm or two concrete walls with thickness < 10 cm

Interfaces

2.5G RJ45 Ports	4
Ethernet Notes	1× WAN port, the rest are LAN ports

LED

System
Internet
Wi-Fi
WPS

Physical Buttons

Power On/Off Button
WPS Button
Reset Button

Power Input

DC Jack

Power

Power Methods	DC
DC	12V 2A
Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 2A DC
Max Power Consumption (W)	22W
Idle Power Consumption (W)	12W

Reliability

Environment	Operating Temperature: 0 ℃ ~ 40 ℃ Storage Temperature: -40 ℃ ~ 70 ℃ Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing
Certifications	FCC, CE

Mechanical

Installation	Desktop Wall-mount
Dimension	253×152.5×48.2 mm
Product Weight	643.4 g

Package Contents:
1 x WT1200
1 x Power Adapter 12v 2A
1 x Ethernet Cable
1 x User Guide

Additional Images:

Return for:
Refund:	Store Credit:	Repair:
20 day(s)	40 day(s)	24 month(s)
