Power Supply » Industrial » AD-155B
155W 26.7V/5.6A PS with Battery Charger (UPS Function)
[AD-155B]
Price: 49,40€
 Order or Qty  Price
 > 500€  5+   48,41€
 > 1000€  10+   47,42€
 > 2000€  20+   46,44€
 > 5000€  40+   45,45€
 > 10000€  100+   44,46€
Prices exclude VAT

155W 26.7V/5.6A PS with Battery Charger (UPS Function)

Available on:
2021-10-19
Expected Qty:5
Order Qty:

The new AD-155B power supply is a specific purpose security series product with battery charger and UPS function.

Features:
 * Wattage: 35W~155W
 * With UPS function (need external batteries)
 * Suitable for security industry or battery backup systems
 * PCB type: PSC series (case available)
 * Universal AC input / Full range
 * Protections: Short circuit / Overload / Over voltage
 * Battery low and battery polarity protection
 * Cooling by free air convection
 * 100% full load burn-in test
 * Fixed switching frequency at PFC 67KHz, PWM 134KHz

Note: Requires 24V battery (2x12V) for UPS function.

Specifications
Output Number CH1 CH2
DC Voltage 27.6V 27.1V
Rated Current 5A 0.5A
Current Range 0-5.5A 0-0.5A
Rated Power 151.55W 151.55W
Input No Load Ripple&Noise 150mVp-p 150mVp-p
Voltage Adj. Range 24-29V ---
Voltage Tollerance +-1.0% ---
Line Regulation +-0.5% ---
Load Regulation +-0.5% ---



Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
