NBE-5AC-19
Ubiquiti NBE-5AC-19, 5GHz NanoBeam AC, 19dBi, AP-CPE
[1506][NBE-5AC-19]
The product is
no longer available
Prices exclude VAT

Ubiquiti NBE-5AC-19, 5GHz NanoBeam AC, 19dBi, AP-CPE

UPC:810354022425

NBE-5AC-19

airMAX ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.

The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.

The NanoBeam ac’s excellent beam directivity provides the best performance in high-noise environments.

The NanoBeam ac mounts to a variety of surfaces including poles or walls, and offers the freedom of three-axis alignment.

Connectors and Interfaces:
LAN speed:  (1) 10/100/1000Mbps
Gigabit LAN:  Yes
Hardware:
RAM memory size:  128 MB
CPU:  Atheros MIPS 74KC
CPU frequency:  720 MHz
Physical characteristics:
Purpose:  Outdoor
Buttons:  Reset
Operating temperature:  -40°C up to 70°C
Weight:  530 mm
Depth:  125 mm
Width:  189 mm
Height:  189 mm
Power:
Max. power consumption:  8 W
Power over Ethernet:  20 .. 26V DC
PoE type:  Input
Software:
Operating mode:  Client, Repeater, AP Router, Access Point, Client Router (wisp)
IPv6 support:  Transparent (bridge mode)
Default IP address:  192.168.1.20
Default login and password:  ubnt / ubnt
Wireless features:
Wireless frequency:  5 GHz
Transmission speed - WiFi 5GHz:  866 Mb/s
WiFi standards:  airMAX ac
Tx power 5GHz:  26 dBm
Security:  WPA2 AES
5GHz MIMO:  2 x 2
Type of antenna:  Build-in
Internal antennas:  2
Antenna gain:  19 dBi


Additional Images:



Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 24 month(s)
