PoE » PoE Injector » EZ-POEWI
Outdoor Passive 10/100 PoE Injector - cat5
[EZ-POEWI]
Price: 1,89€
 Order or Qty  Price
 > 500€  5+   1,85€
 > 1000€  10+   1,81€
 > 2000€  20+   1,78€
 > 5000€  40+   1,74€
 > 10000€  100+   1,70€

Outdoor Passive 10/100 PoE Injector - cat5

In Stock: 2
Order Qty:

EZ-POEWI

Features:

  • Cat5 Cable
  • RJ45 Input / Output connector
  • Input / Output common ground
  • Power / Data Injector
  • Ethernet switches expand to Wireless AP
Input / Output Specifications :
DC Input Voltage 48V ± 5 %
DC Output Voltage 48V ± 5 %
Max Output Current 0.4A Max.
Over Current Protection None
General Specifications:
Operating Temperature 0oC ~ +50oC
Storage Temperature -20oC ~ +70oC
Humidity Up to 90%
Weight 50gr
Dimensions 160x22x21mm
Input Pins
RJ-45 Plug
Output Pins
RJ-45 Jack
1 Tx(+) Tx(+) 1
2 Tx (-) Tx (-) 2
3 Rx (+) Rx (+) 3
4 N.C. V+ 4
5 N.C. V+ 5
6 Rx (-) Rx (-) 6
7 N.C. GND 7
8 N.C. GND 8


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
