LANKON-008
LANKON-008 - IP Managed Lan Controller HW3.8
[1878][LANKON-008]
The product is
no longer available
Prices exclude VAT

LANKON-008 - IP Managed Lan Controller HW3.8

EAN:5903968144210

Applies to hardware version HW v3.8

Compared to version 3.0, version 3.8 has a faster processor with a 108MHz clock, more RAM and flash memory.

The INPA1-2 analog inputs have an extended voltage range up to 5V/55V. This allows you to work with a more sensitive measuring range also for sensors whose signal reaches 5V.

The battery connector, supporting the power supply of registers, will allow to implement the RTC clock and remember the status of outputs before the power reset (planned option).

The most important change is the addition of transmission encryption support. Thanks to this, you can use https, mqtts SNMPv3 connections and use e-mail servers that require outgoing e-mail authentication, e.g. Gmail.

Specifications:
Supply voltage 8-55V
Power consumption 0.5W (relays off)
PoE power supply YES (passive)
Ethernet
1*LAN 10/100Mbps
Relay 255VAC 10A
Operating temperature -20°C to +85°C
Dimensions 60 x 68mm
Weight 50g


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
