Waterproof DC Jack Panel Mount 3A 5.5 x 2.1mm
[IOT-WDCJ]
Price: 0,14€
 Order or Qty  Price
 > 500€  5+   0,14€
 > 1000€  10+   0,13€
 > 2000€  20+   0,13€
 > 5000€  40+   0,13€
 > 10000€  100+   0,13€
Prices exclude VAT

Waterproof DC Jack Panel Mount 3A 5.5 x 2.1mm

In Stock: 17
Order Qty:

IOT-WDCJ

Waterproof 5.5 x 2.1mm DC Power Jack Chasis Mount Connector

Specifications :
Model Number IOT-WDCJ
Matched male plug 5.5*2.1 and 5.5*2.5
Material PBT plastic & Brass NI, never use recycle plastic.
Temperature -20°C--+120°C
Rated voltage 30VDC 5A
Insulation resistance ≥100mΩ
Contact Resistance ≤0.03Ω
Insertion force 3-20 N
Withstand voltage 500VAC (50Hz)/min
Lifetime 5000 times at a speed of 10-25 cycles/minute
Application Power, Panel amount for power
Certification CE, FCC, ROSH, REACH


Additional Images:

Return for:
Refund: Store Credit: Repair:
20 day(s) 40 day(s) 12 month(s)
