MaxLink POESG-8-7P, 8x GLAN, 7x PoE + 60W Power Adapter 24V 2.5A

POESG-8-7P - MaxLink 8 x Gbps ports, 7 x PoE + 1 x UpLink with a 60W power adapter (24v 2.5A)

This un-managed Gigabit passive PoE switch has 8 x 10/100/1000Mbps ports.

The first seven (1-7) ports can be configured as PoE out while the eighth (8) is the Uplink port.

Features:

• 8 ports 10/100/1000Mbps switch
• 7 ports with the PoE out function
• 1 Uplink port
• Mode A using pins 1,2+ and 3,6-
• Mode B using pins 4,5+ and 7,8-
• Overvoltage protection on each port - Mode A (650 mA/port), Mode B (1000 mA/port)
• Maximum current 2.5 A
• Wide range of input/output voltage (18v – 56v DC)
• Included 24v adapter (output voltage is same for both modes as input)
• Option to choose POE Mode A / Mode B / PoE OFF (not both Mode A AND Mode B)
