VAMI VMBF-51280, 14.34 kWh, LV, battery on wheels

Price: 1.568,77€

Order or Qty		Price
> 500€	5+	1.553,08€
> 1000€	10+	1.537,40€
> 2000€	20+	1.521,71€
> 5000€	40+	1.506,02€
> 10000€	100+	1.490,33€

Prices exclude VAT

VAMI VMBF-51280, 14.34 kWh, LV, battery on wheels

Ships in:
3-5 working days

Order Qty:

Product Details
PID:	3661
SKU:	VMBF-51280
Weight:	125.00 Kgs
Return Policy
Refund:	20 days
Store Credit:	40 days
Repair / Warranty:	120 months

VMBF-51280 - 14.34 kWh, LV, battery on wheels.

high‑capacity, floor‑standing LiFePO4 energy storage unit for indoor use.

It stores about 14.34 kWh (280 Ah) at 51.2 V, supports up to 200 A charge/discharge with short peaks, and is designed for residential or small commercial solar setups.

Built‑in BMS, a 4.3‑inch display, and RS‑485/CAN communication make system monitoring and inverter integration straightforward, and multiple units can be paralleled for larger capacity.

The model is rated for up to roughly 6 000 cycles and comes on wheels for easier positioning.

Product Links:
Datasheet	User Manual

Specifications:
Battery Capacity [kWh]	14.34 kWh
Battery Capacity [Ah]	280 Ah
Output Voltage [V]	51.2 V
Battery System	Low voltage
Max. Charging/Discharging Current	200 A
Depth of Discharge (DoD)	90%
Max. Parallel Modules/Stack	16
Interface & Control
Display Size	4.3"
Other Features	Touchscreen
Communication Interface	RS-485, CAN
Physical & Environmental
Battery Type	LiFePO4 (Lithium Iron Phosphate)
Design / Purpose	Tower / Indoor
Protection Class	IP20
Operating Temperature	0 to 55 °C
Weight	125 kg
Dimensions (H x W x D)	840 x 530 x 255 mm

Package Contents:
1 x VMBF-51280 Battery
2 x DC Cables (1xBlack+1xRed), 1m
1 x Inverter communication cable
1 x Battery communication cable
1 x User Manual
1 x Warranty document
