Specifications: |
|
Max Throughput (PTP) |
1.0 Gbps IP aggregate |
|
Max Throughput (PTMP) |
750 Mbps IP aggregate UL/DL |
|
Wireless Protocols |
WiFi Interop; Auto-TDD (future); PTMP TDMA (future) |
|
Modes |
PTP backhaul, PTMP client |
|
Radio |
|
MIMO & Modulation |
2x2, PTMP MU-MIMO, OFDMA (future), BPSK-1024QAM |
|
Bandwidth |
80 MHz channels (streamlined) |
|
Frequency Range |
5150–6425 MHz (restricted by country of operation) |
|
Max Output Power |
27 dBm |
|
Rx Sensitivity (MCS 0) |
-90 dBm @ 80 MHz | -93 dBm @ 40 MHz | -96 dBm @ 20 MHz |
|
Power |
|
Max Power Consumption |
20 W |
|
System Power Method |
Passive PoE |
|
PoE Power Supply |
Compliant, 24 V (PoE injector not included) |
|
Compatible PoE Injector (Sold Separately) |
502-00030 (PoE Injector 24V 30W) |
|
Physical |
|
Dimensions (H x W x D) |
175 x 70 x 61 mm |
|
Weight |
0.7 kg |
|
RF Connector Type |
Mimosa N5-X twist-on |
|
Enclosure Characteristics |
Die-cast aluminum, UV stabilized paint, with outdoor UV stable plastic radome lens |
|
Mounting |
Dual-pole strap capable |
|
Grounding |
Ground lug |
|
Environmental |
|
Outdoor Ingress Protection Rating |
IP67 |
|
Operating Temperature |
-40° C to + 55° C |
|
Operating Humidity |
5 to 100% Condensing |
|
Operating Altitude |
4,420 m maximum |
|
Shock and Vibration |
ETS 300-019-2-4 class 4M5 |
|
Features |
|
Gigabit Ethernet |
10/100/1000-BASE-T |
|
Management Services |
MMP support; SNMPv2c/v3; Syslog; HTTPS; HTML 5 based Web GUI; IPv4 and IPv6 |
|
Smart Spectrum Management |
Active scan monitors/logs ongoing RF interference across all channels
Dynamic auto-optimization of channel and bandwidth use |
|
Security |
AES; RADIUS; 802.1x authorization (future) |
|
VLAN |
Q-in-Q (future), double tagging, management VLAN, PTMP per client VLAN |
|
Regulatory and Compliance |
|
Approvals |
FCC Part 15.407; IC RSS210; CE (RED, EMCD, VLD, RoHS); ETSI 301 893/302 502 |
|
RoHS Compliance |
Yes |
|
Safety |
EN 62638-1 |
|
Part Number |
100-00114 |
