CCR1036-8G-2S+EM
The new CCR1036-8G-2S+ now has two SFP+ ports for 10G interface support (SFP+ module available separately).
It uses the same 36 core Tilera CPU as our other CCR1036 model, and delivers the same performance, but now, ten gigabit links are possible.
The device comes in a 1U rackmount case, has two SFP+ ports, eight Gigabit ethernet ports, a serial console cable and a USB port.
It has two SODIMM slots, by default it is shipped with 4GB of RAM, but has no memory limit in RouterOS (will accept and utilize 16GB or more). Also available now, the EM model with 16GB of RAM!
Supports both SFP (1.25G) and SFP+ (10G) modules
|
Specifications: |
|
Product code: |
CCR1036-8G-2S+EM |
|
CPU nominal frequency: |
1.2 GHz |
|
SFP DDMI: |
Yes |
|
CPU core count: |
36 |
|
Architecture: |
TILE |
|
Size of RAM: |
16 GB |
|
10/100 Ethernet ports: |
0 |
|
10/100/1000 Ethernet ports: |
8 |
|
MiniPCI slots: |
0 |
|
MiniPCI-e slots: |
0 |
|
Wireless chip model: |
None |
|
Number of USB ports: |
1 |
|
Memory Cards: |
1 |
|
Memory card type: |
microSD |
|
Power Jack: |
1 |
|
Supported input voltage: |
28 V - 18 V |
|
PoE in: |
No |
|
PoE out: |
No |
|
Voltage Monitor: |
Yes |
|
PCB temperature monitor: |
Yes |
|
CPU temperature monitor: |
Yes |
|
Dimensions: |
355 x 145 x 55 mm |
|
Operating System: |
RouterOS |
|
Operating temperature range: |
-30°C to +60°C |
|
License level: |
6 |
|
Antenna gain DBI: |
No |
|
Current Monitor: |
Yes |
|
CPU: |
TLR4-03680CG-12CE-A3b |
|
SFP ports: |
0 |
|
SFP+ ports: |
2 |
|
USB slot type: |
microUSB type AB |
|
Number of chains: |
0 |
|
Serial port: |
RS232 |
