E62iUGS-2axD5axT - hAP ax S
Triple-chain 5 GHz radio (up to 900 Mbit/s throughput), dual-band Wi-Fi 6, 5x Gigabit Ethernet ports, and a 2.5G SFP.
Powered by a dual-core ARM CPU, with PoE-in/PoE-out flexibility, a standard DC jack, USB, and a sturdy high-end enclosure that can be mounted on the wall.
DC jack or PoE-in, and a passive PoE-out port to power another MikroTik device
|
Specifications: |
|
Product code |
E62iUGS-2axD5axT |
|
Architecture |
ARM 32-bit |
|
CPU |
EN7562CT (950 MHz Dual-Core) |
|
Size of RAM |
512 MB |
|
Storage size/type |
128 MB NAND |
|
Operating System/License |
RouterOS v7 / Level 4 |
|
IPsec hardware acceleration |
Yes |
|
MTBF (Approx) |
100.000 hours at 25°C |
|
2.4 GHz |
|
Max data rate |
574 Mbit/s |
|
Standards/Generation |
802.11b/g/n/ax / Wi-Fi 6 |
|
Number of chains |
2 |
|
Antenna gain |
5.5 dBi |
|
Chip model |
MT7916 |
|
5 GHz |
|
Max data rate |
1800 Mbit/s |
|
Standards/Generation |
802.11a/n/ac/ax / Wi-Fi 6 |
|
Number of chains |
3 |
|
Antenna gain |
8.07 dBi |
|
Chip model |
MT7976 |
|
Ethernet & Fiber |
|
10/100/1000 Ethernet ports |
5 |
|
Number of 1G Ethernet ports with PoE-out |
1 |
|
SFP ports |
1 (2.5G supported) |
|
Peripherals |
|
Number of USB ports |
1 |
|
USB slot type |
USB type A |
|
Max USB current (A) |
1 A |
|
USB Power Reset |
Yes |
|
Powering |
|
Number of DC inputs |
2 (DC jack, PoE-IN) |
|
DC jack input Voltage |
12-28 V |
|
PoE in input Voltage |
18-28 V (Passive PoE) |
|
Max power consumption (total) |
34 W |
|
Max power consumption (w/o attachments) |
11 W |
|
Cooling type |
Passive |
|
PoE-out |
|
PoE-out ports |
Ether5 |
|
PoE out type |
Passive PoE |
|
Low voltage PoE-Out current limit |
0.6 A |
|
Total output power |
16.8 W |
|
Other & Environment |
|
Tested ambient temperature |
-40°C to 70°C |
|
Certification |
CE, FCC, IC, EAC, ROHS |
|
IP rating |
IP20 |
|
CPU temperature monitor |
Yes |
| Package Contents: |
|---|
| 1 x hAP ax S
|
| 1 x 24V 1.5A power adapter |
|
