Outdoor 5.xGHz » RBLHG-5HPnD-XL
MikroTik LHG XL HP5 , 27dBi, 802.11a/n, ROS L3, PoE
[RBLHG-5HPnD-XL]
Price: 70,74€
 Order or Qty  Price
 > 500€  5+   70,03€
 > 1000€  10+   69,33€
 > 2000€  20+   68,62€
 > 5000€  40+   67,91€
 > 10000€  100+   67,20€
Prices exclude VAT

MikroTik LHG XL HP5 , 27dBi, 802.11a/n, ROS L3, PoE

In Stock: 3
Order Qty:

LHG XL HP5

The LHG XL HP5 is a 5GHz 802.11 a/n wireless device with an integrated dual polarization 27 dBi grid antenna and 630mW TX output power.

Designed to reach up to 40km in point-to-point setups at full speed.

The grid design ensures protection against wind, and the fact that the antenna element is built into the wireless unit means no loss on cables.

LHG XL HP5 supports 5150MHz-5875MHz range.

Description:
Licence level 3
CPU nominal frequency 600 MHz
Size of RAM 64 MB
Storage type Flash
Storage size 16 MB
10/100 Ethernet ports 1
Wireless Built-in 5 GHz 802.11a/n, dual-chain
Wireless chip model AR9344
Operating frequency 5150 - 5875 MHz
Antenna gain 27.5 +/- 0.5 dBi
Antenna beam width 6.4°
PoE in Yes - Passive PoE
Supported input voltage 10 V - 28 V
Wind Survivability 205 km/h
Wind Loading 186N @ 205 km/h
Cross polar 21 dBi
Port to port isolation 20 dB
Front to back ratio 25 dB
Operating Temperature -40°C to 70°C
Operating Humidity 5 to 95% noncondensing
Shock and Vibration ETSI300-019-1.4
ETSI specification EN 302 326 DN2
Dimensions Unit: 550 x 245 mm
Package: 585 x 595 x 138 mm
Weight Unit: 945 g
Package: 2.99 kg
Max Power consumption 7 W
