mANTBox 19s - 5GHz 120 degree 19dBi dual polarization sector Integrated antenna with 720Mhz CPU, 128MB RAM, SFP, PSU and PoE
The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high speed 720MHz CPU and has a built in 802.11 ac/a/n wireless device with up to 31dBm output power.
mANTBox 19s comes with 19dBi 120 degree sector antenna.
RB921GS-5HPacD-19S supports 5.17 - 5.835 GHz range (Specific frequency range can be limited by country regulations).
|
Specifications |
|
Product code |
RB921GS-5HPacD-19S |
|
CPU |
QCA9557 |
|
CPU core count |
1 |
|
CPU nominal frequency |
720 MHz |
|
Dimensions |
152 x 598 x 78 mm |
|
License level |
4 |
|
Operating System |
RouterOS |
|
Size of RAM |
128 MB |
|
Storage size |
128 MB |
|
Storage type |
NAND |
|
Tested ambient temperature |
-40°C to 70°C |
|
Powering |
|
PoE in |
Passive PoE |
|
PoE in input Voltage |
12-28 V |
|
Number of DC inputs |
2 (PoE-IN, DC jack) |
|
DC jack input Voltage |
8-30 V |
|
Max power consumption |
13 W |
|
Wireless |
|
Wireless 5 GHz Max data rate |
867 Mbit/s |
|
Wireless 5 GHz number of chains |
2 |
|
Wireless 5 GHz standards |
802.11a/n/ac |
|
Antenna gain dBi for 5 GHz |
19 |
|
Wireless 5 GHz chip model |
QCA9892 |
|
Wireless 5 GHz generation |
Wi-Fi 5 |
|
Ethernet |
|
10/100/1000 Ethernet ports |
1 |
|
Fiber |
|
SFP ports |
1 |
|
Other |
|
PCB temperature monitor |
Yes |
|
Voltage Monitor |
Yes |
