Aerial.net :: MikroTik C53UiG+5HPaxD2HPaxD, hAP ax³

MikroTik » SOHO wireless » C53UiG+5HPaxD2HPaxD

MikroTik C53UiG+5HPaxD2HPaxD, hAP ax³
[2907][C53UiG+5HPaxD2HPaxD]

Price: 102,95€

Prices exclude VAT

Available after:
1 Jul 2026

Order Qty:

EAN:	4752224007940

hAP ax³ - Gen 6 wireless, 2.5 Gigabit Ethernet, PoE, WPA3, and more!

hAP ax3 is our most powerful AX device with the best wireless network coverage so far.

It features a modern quad-core ARM CPU running at 1.8 GHz and enough memory (1GB RAM + 128 MB NAND) for most tasks.

AX product family offers up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum

4x Gigabit Ethernet ports and an ultra-fast 2.5 Gigabit port. Added a speedy USB 3 port for storage purposes or an additional LTE modem.

Product Links:
Product Page	Quick Guide	Brochure	Manual

Peripherals
Number of USB ports	1
USB Power Reset	Yes
USB slot type	USB 3.0 type A
Max USB current (A)	1
Powering
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	12-28 V
Max power consumption	38 W
Max power consumption without attachments	15 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	18-28 V
PoE-out
PoE-out ports	Ether 1
PoE out	Passive PoE
Max out per port output (input 18-30 V)	0.625 A
Max total out (A)	0.625 A
Total output current	0.625
Total output power	15
Certification & Approvals
Certification	CE, FCC, IC, EAC, ROHS
Other
CPU temperature monitor	Yes
Mode button	Yes
Specifications
Product code	C53UiG+5HPaxD2HPaxD
Architecture	ARM 64bit
CPU	IPQ-6010
CPU core count	4
CPU nominal frequency	auto (864 - 1800) MHz
RouterOS license	6
Operating System	RouterOS v7
Size of RAM	1 GB
Storage size	128 MB
Storage type	NAND
MTBF (Approximately)	200'000 hours at 25°C
Tested ambient temperature	-40°C to 70°C
IPsec hardware acceleration	Yes
Wireless capabilities
Wireless 2.4 GHz Max data rate	574 Mbit/s
Wireless 2.4 GHz number of chains	2
Wireless 2.4 GHz standards	802.11g/n/ax
Antenna gain dBi for 2.4 GHz	3.3
Wireless 2.4 GHz chip model	QCN-5022
Wireless 2.4 GHz generation	Wi-Fi 6
Wireless 5 GHz Max data rate	1200 Mbit/s
Wireless 5 GHz number of chains	2
Wireless 5 GHz standards	802.11a/n/ac/ax
Antenna gain dBi for 5 GHz	5.5
Wireless 5 GHz chip model	QCN-5052
Wireless 5 GHz generation	Wi-Fi 6
WiFi speed	AX1800
Ethernet
10/100/1000 Ethernet ports	4
Number of 1G Ethernet ports with PoE-out	1
Number of 2.5G Ethernet ports	1

Additional Images:

Return for:
Refund:	Store Credit:	Repair:
20 day(s)	40 day(s)	24 month(s)
