This PTZ camera series is a high-performance device for use in professional and demanding surveillance situation.
AVP322 is a PTZ camera with 22X zoom lens to help you widen your surveillance area. You can set the camera on patrol to several points regularly, or move to any place you like and zoom in up to 22X ratio to see things clearly.
|
General |
|
Signal System |
NTSC or PAL |
|
Pick-up Element |
1/4" Sony Color Super HAD CCD image sensor |
|
Number of Pixels |
768(H)*494(V)<NTSC> / 752(H)*582(V)<PAL> |
|
Resolution |
High Resolution |
|
Min. Illumination |
0.6 Lux / F1.6 |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Video Output |
1.0 Vp-p. 75Ω |
|
BLC |
On / Off |
|
Gain Control |
Low, Medium & High / Off |
|
Sharpness |
Auto / Low / Medium / High |
|
White Balance |
Auto / Indoor 1 / Indoor 2 / Sun / Cloudy
* Indoor1 = 9000K; Indoor2 = 3000K; Sun = 5500K; Cloudy = 7000K |
|
Camera Title |
10 characters or symbols |
|
Preset Points and Sequence |
Total 8 groups, 256 programmable preset points
* The sequence of all the preset points will follow the order of the minimal
panning route. |
|
Auto Tracking |
Yes |
|
Lens |
|
Video Compression |
MPEG4 / MJPEG |
|
Video Remote Control |
YES |
|
Video Adjustment |
Brightness, Contrast, Saturation and Hue |
|
Audio Compression |
uLaw , 128kbps |
|
Audio Input |
External Microphone Input |
|
Camera |
|
Focal Length |
f3.9 mm ~ f85.9 mm |
|
F-number |
F1.6 (Wide) ~ 3.7 (Tele) |
|
Viewing Angle |
4∘~ 60∘ |
|
Auto Electronic Shutter |
1 / 60 (1/50) to 1 / 100,000 sec. |
|
Auto Focus |
Always / PTZ / Z Only / P Only |
|
Mechanism |
|
Pan Range |
360∘ |
|
Pan Speed |
360∘/ 1 sec
* The pan speed can be adjusted according to the different pan speed mode. |
|
Tilt Range |
90∘ |
|
Tilt Speed |
0∘~ 90∘under 1 sec |
|
Zoom Ratio |
22X optical zoom |
|
Zoom Speed |
Approx. 7s (Tele ~ Wide) |
|
Other |
|
IP Rating |
IP66 |
|
Ambient Operating Temperature |
-20∘~ 40∘(-4°F ~ 104°F) |
|
Storage Temperature |
0∘~ 70∘ |
|
Power Source (±10%) |
DC12V- INCLUDED |
|
Current Consumption |
1.5 A (max) |
|
Dimension (mm)** |
145(Ø) x 184(H) (Bracket not included) |
|
Gross Weight (g) |
Approx. 1.2 kg |
|
Optional Bracket |
Wall-mounted - INCLUDED |
|
Optional Device |
Keyboard controller |
